WAREHOUSE Equipment and Supply Co: Hand Trucks

   Frame   + Handle  + Nose Plate  + Wheels  = Model
         F1        PLT       CA2           FN2     F1-PLT-CA2-FN


F1	F2	F3
STANDARD FIXED FRAME A stress resistant, straight frame for general use offers maximum shock absorption and durability	STANDARD FIXED FRAME WITH ALUMINUM CENTER STRAP A stress resistant, straight frame with mounted vertical strap offers easy transport of smaller items	STANDARD FIXED FRAME WITH SOLID ALUMINUM DECK This frame allows transport of smaller and odd shaped items.

F4		F5
CURVED FIXED FRAME A curved frame to transport cylinders, bottled water and kegs with solid molded curved crossbars for superior strength and safety. Cylinders nest into the frame.		CURVED FIXED FRAME WITH STRAIGHT TOP CROSSBAR A curved fixed frame with a straight top crossbar for transporting cases on top of cylinders.


DGV	SLP	SLV
DUAL GRIP VINYL The dual grip handle comes with an E4 (44”) channel extension. The total hand truck height with this handle is 48”.	SINGLE LOOP PLAIN The single loop handle is made of smooth aluminum for easy handling. The total hand truck height with this handle is 50”.	SINGLE LOOP WITH VINYL SLEEVE The loop handle with vinyl sleeve provides an easy to grip cushioned handle. The total hand truck height with this handle is 50”.

PLT	PLC	VLP
SINGLE TOP GRIP HANDLE The easy to use loop handle has a welded pin grip at the top. The total hand truck height with this handle is 52”.	SINGLE CENTER GRIP HANDLE The loop handle with cross brace and welded pin grip for easy one-hand toting. The total hand truck height with the handle is 55”.	VERTICAL LOOP PLAIN The vertical loop handle provides easy maneuverability. The total hand truck height with this handle is 53”.

VLC	DL1	DL2
VERTICAL LOOP FOR CURVED FRAME The vertical loop handle for the curved frame provides easy maneuverability. The total hand truck height with this handle is 53”.	55" DUAL LOOP HANDLE The dual loop handle provides extra support for taller loads. The dual loop also provides added safety.	60" DUAL LOOP HANDLE The dual loop handle provides extra support for taller loads. The dual loop also provides added safety.

CA1

CA2

EA1

CAST ALUMINUM

Cast aluminum nose plate is 14” wide x 7.5” deep, with a recessed heel.

CAST ALUMINUM

Cast aluminum nose plate is 18” wide x 7.5” deep, with a recessed heel.

EXTRUDED ALUMINUM

Industrial strength nose plate is 18” wide x 9” deep. This plate mounts on the front of the truck frame.

EA2	EA3	EA4
EXTRUDED ALUMINUM Industrial strength nose plate is 18” wide x 7.5” deep. This plate mounts behind the frame and has cut outs for wheels.	EXTRUDED ALUMINUM Industrial strength nose plate is a 14” wide x 9” deep. This plate mounts on the front of the truck frame.	EXTRUDED ALUMINUM Industrial strength nose plate is a 14” wide x 7.5” deep. This plate mounts behind the frame and has cut outs for wheels.


FN2	SW1	SWS
FULLY PNEUMATIC 4-PLY 10" A great general-purpose wheel with a 4 ply, 2-piece hub, zerk fitting, and ball bearings. Capacity is 350 lbs. per wheel*. Weighs 4.50 lbs.	SIGNATURE WHEEL 8" A lightweight, strong offset nylon core with high strength non-marking elastomeric rubber tread. The round tread provides easy rolling. This wheel comes with sealed ball bearings. Capacity is 600 lbs. per wheel.* Weighs 2.30 lbs.	SIGNATURE WHEEL 10" Wheel is the same as SW1 but has a capacity of 800 lbs.* per wheel and weighs 3 lbs.

SN1		SF1
SEMI-PNEUMATIC 10" Easy rolling maintenance-free tire with ball bearings provides shock absorption and long life. Capacity is 500 lbs. per wheel.* Weighs 4.90 lbs.		SOLID FOAM MAINTENANCE-FREE 10" The solid foam tire with sealed ball bearings performs like a pneumatic and never goes flat. Capacity is 300 lbs. per wheel.* Weighs 4.25 lbs.


KWIK-LOAD JR.		KWIK-LOAD SR.


N1 20" Long Folding Nose Extension N2- 30" Long
